| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
72 pcs
|
72 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Cable Termination | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Type | |
| Fastening Type | |
| Features | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Pitch | |
| Row Spacing | |
| SVHC Present | |
| Storage Temperature | |
| Termination Style | |
| Wire Gauge | |
| Wire Type |
The M80-4C15005FC is a 50 position (25+25) female receptacle connector from Harwin's Datamate J-Tek series. It is designed for free hanging (in-line) cable-to-cable or cable-to-board applications. The connector features a 2.00mm pitch with 2 rows of contacts, and uses crimp termination for 24-28 AWG discrete wires. Contacts are gold plated with a thickness of 0.30µm (11.8µin) for reliable signal integrity.
The housing is black and includes jackscrews and a polarizing key for secure mating and alignment. The connector is rated for currents up to 3.3A per contact under specific conditions (one contact loaded at 25°C ambient). It is part of the Datamate family known for high-reliability interconnects in demanding environments.
The connector is supplied as a complete kit including the housing and 50 straight signal contacts. It uses 101Lok bayonet fixings for fast mating and release. The mounting type is free hanging (in-line), making it suitable for cable assemblies where panel mounting is not required.
50 positions (25+25).
2.00mm (0.079").
Up to 3.3A per contact at 25°C ambient (one contact loaded).
Free hanging (in-line).
Gold with 0.30µm thickness.
24-28 AWG discrete wires.
Screw lock (jackscrews).
