| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
9 pcs
|
9 pcs | On Request | 3 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Adjustment Type | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Turns | |
| Power (Watts) | |
| Resistance | |
| Resistive Material | |
| Storage Temperature | |
| Tape & Reel | |
| Temperature Coefficient | |
| Temperature Range | |
| Termination Style | |
| Tolerance | |
| Weight |
The Vishay Dale M63P102KB40 is a professional-grade, single-turn cermet trimmer potentiometer. It features a resistance value of 1 kΩ with a tolerance of ±10% and a power rating of 0.5W at +70°C, derated linearly to 0W at 125°C. The trimmer offers side adjustment and PC pin termination for through-hole mounting.
Designed for reliable performance, this trimmer operates within a temperature range of -55°C to +125°C and has a sealing of IP64. Key electrical specifications include an end resistance of 2 Ω or 1% (whichever is greater), a dielectric withstand voltage of 1000 V AC, and an insulation resistance of 1000 MΩ minimum. The mechanical specifications include a mechanical travel of 300° ± 50 and a starting torque of 35 mNm max.
This component is suitable for applications requiring precise resistance adjustments in various electronic circuits. Its robust construction and environmental sealing make it suitable for demanding environments.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance value is 1 kΩ.
The tolerance is ±10%.
The power rating is 0.5W at +70°C, derated linearly to 0W at 125°C.
The typical temperature coefficient of resistance is ±100ppm/°C.
It is designed for through-hole mounting.
The operating temperature range is -55°C to +125°C.
The sealing rating is IP64.
