Mfr Part #:

M5M5V408BFP-70H

Mfr Name: REN

The M5M5V408BFP-70H is a 4-Mbit CMOS Static RAM from Renesas Electronics. It operates on a single 2.7V to 3.6V power supply.

✓ Total Stock: 2,250 pcs

M5M5V408BFP-70H Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Husky International Electronic ✓ Non-Authorised Inventory information	2,250 pcs On Request	2250 pcs	On Request	1	On Request	On Request	N/A	On Request	On Request

M5M5V408BFP-70H Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	REN
Mounting Type	Surface Mount
Package / Case	SOP 32
Technology	0.25µm CMOS

View Similar Products (0)

M5M5V408BFP-70H Description

Short technical summary and product information.

The M5M5V408BFP-70H is a 4-Mbit CMOS Static RAM manufactured by Renesas Electronics. It is organized as 524,288 words by 8-bit and fabricated using high-performance 0.25µm CMOS technology.

This RAM features a single power supply voltage range of 2.7V to 3.6V, making it suitable for low-voltage applications. It offers a small standby current of 0.3µA typical at 3V and requires no clocks or refresh cycles. The data retention supply voltage ranges from 2.0V to 3.6V.

All inputs and outputs are TTL compatible. The M5M5V408BFP-70H is packaged in a 32-pin plastic SOP, suitable for surface mounting. This component is designed for memory applications where simple interfacing, battery operation, and battery backup are important design objectives.

M5M5V408BFP-70H Quick Information

Product Type: CMOS Static RAM

Series: M5M5V408BFP

Canonical Name: M5M5V408BFP-70H CMOS Static RAM

Subcategory: Memory

M5M5V408BFP-70H Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

M5M5V408BFP-70H Features

4-Mbit CMOS Static RAM
Organized as 524288 words by 8-bit
Single 2.7V to 3.6V power supply
Low standby current: 0.3µA typical
32-pin SOP package

M5M5V408BFP-70H Applications

Battery-operated portable electronic devices.
Battery backup memory systems.
Low-power data storage applications.
Simple interfacing memory designs.

M5M5V408BFP-70H FAQs

5 frequently asked questions generated from this part’s specifications.

What is the supply voltage range for the M5M5V408BFP-70H?

The supply voltage range is 2.7V to 3.6V.

What is the standby current of this SRAM?

The typical standby current is 0.3µA at 3V.

Down to what voltage can the M5M5V408BFP-70H retain data?

Data retention is guaranteed from 2.0V to 3.6V.

What is the memory organization of the M5M5V408BFP-70H?

It is organized as 524,288 words by 8 bits (4 Mbits total).

What package is the M5M5V408BFP-70H available in?

The device is offered in a 32-pin SOP (Small Outline Package) for surface mount.
