The Harwin M52-040023V1045 is a 10-position, single row, unshrouded male pin header from the Archer M52 series. It features a 1.27mm pitch and is designed for through hole mounting with straight solder terminations. The connector uses square brass pins with a gold flash finish on the contact area and terminations.
The insulator is molded from black polyamide (PA6T/Nylon 6T) with a UL94 V-0 flammability rating. The header has a push-pull fastening type and is intended for board-to-board applications. The overall contact length is 8.80mm, with a mating pin height of 4.00mm and an insulation height of 2.50mm.
This connector is rated for a current of 1A per contact and has an operating temperature range of -40°C to 105°C. The initial contact resistance is a maximum of 20mΩ per EIA-364-06C.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.47 | $1.47 |
| 10+ | $1.26 | $1.26 |
| 100+ | $1.07 | $1.07 |
| 500+ | $0.95 | $0.95 |
| 1,000+ | $0.92 | $0.92 |
| 2,500+ | $0.90 | $0.90 |
| 5,000+ | $0.81 | $0.81 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The M52-040023V1045 has 10 positions.
The pitch is 1.27mm.
The current rating is 1A per contact.
The mounting type is through hole.
The operating temperature range is -40°C to 105°C.
The contact material is brass with a gold flash finish.
The insulator has a UL94 V-0 flammability rating.
