The Harwin M50-3600542 is a 10-position (5+5) double row male pin header from the Archer M50 series, featuring a 1.27mm pitch and surface mount termination. This unshrouded header has a push-pull fastening type and is designed for board-to-board or cable connections. The mating pin length is 3.00mm, and the connector has an insulation height of 1.00mm. The housing is molded from black thermoplastic rated UL94 V-0, and the copper alloy contacts have a gold flash finish on the mating area with tin on the termination tails.
The electrical rating is 1A per contact (EIA-364-70A maximum), with a maximum initial contact resistance of 20mΩ. The operating temperature range spans -40°C to 105°C. This connector is suitable for compact electronic assemblies where space is limited, and the 1.27mm row spacing provides a dense interconnect solution.
The component is packaged loose in box. Compliance information includes RoHS3 (unverified), REACH unaffected (unverified), and MSL 1 (unverified).
| Qty | Low | High |
|---|---|---|
| 1+ | $1.41 | $1.41 |
| 10+ | $1.20 | $1.20 |
| 100+ | $1.02 | $1.02 |
| 500+ | $0.91 | $0.91 |
| 1,000+ | $0.86 | $0.86 |
| 2,000+ | $0.84 | $0.84 |
| 5,000+ | $0.76 | $0.76 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
10 positions (5+5), all loaded.
1.27mm (0.050").
1A per contact maximum (EIA-364-70A).
Surface mount (SMT) with solder termination.
-40°C to 105°C.
Copper alloy contacts with gold flash on the mating area and tin on the termination tails.
Thermoplastic housing, UL94 V-0 rated.
