The Harwin M50-3501042 is a 20 position (10+10) double row male pin header from the Archer M50 series. It features a 1.27mm pitch and 1.27mm row spacing, making it suitable for high-density board-to-board or cable connections. The connector has a straight through hole mounting style with solder termination and an unshrouded push-pull fastening type.
Key specifications include a 1A per contact current rating, an operating temperature range of -40°C to 105°C, and a UL94 V-0 flammability rating for the thermoplastic insulator. The contact material is copper alloy with a gold finish on the contact area and a tin finish on the termination tails. The mating pin height is 3.00mm and the overall contact length is 6.30mm.
This connector is designed for applications requiring a reliable and compact interconnection solution. The 1.27mm pitch allows for space savings on the PCB, while the through hole mounting provides a robust mechanical connection.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.36 | $2.36 |
| 10+ | $2.01 | $2.01 |
| 100+ | $1.71 | $1.71 |
| 500+ | $1.52 | $1.52 |
| 1,000+ | $1.44 | $1.44 |
| 5,000+ | $1.29 | $1.29 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The M50-3501042 has 20 positions arranged in a 10+10 double row configuration.
The pitch is 1.27mm (0.050") and the row spacing is also 1.27mm.
The maximum current rating is 1A per contact.
The mounting type is through hole with solder termination.
The operating temperature range is -40°C to 105°C.
The contact area has a gold finish, and the termination tails have a tin finish.
The insulator material has a UL94 V-0 flammability rating.
