| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
28 pcs
|
28 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Resistance | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| SVHC Present | |
| Style | |
| Termination |
The Harwin M50-3201045 is a 20 position (10+10) dual row female receptacle part of the Archer M50 series. It features a 1.27mm (0.050") pitch and 1.27mm row spacing, making it suitable for high density board-to-board and cable-to-board interconnects. The connector has a through hole right angle mounting style with 2.4mm solder tails, and is designed for a 105°C maximum operating temperature and 1A current rating. The contact material is copper alloy with gold plating (10µin thickness) ensuring reliable electrical performance. The housing is black high temperature thermoplastic with UL94 V-0 flammability rating. This connector is commonly used in applications requiring compact and reliable connections.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.75 | $3.75 |
| 10+ | $3.60 | $3.60 |
| 25+ | $2.87 | $2.87 |
| 88+ | $2.65 | $2.65 |
| 528+ | $2.40 | $2.40 |
| 1,012+ | $2.29 | $2.29 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The M50-3201045 has 20 positions (10+10 dual row).
The pitch is 1.27mm (0.050").
The maximum current rating is 1A per contact.
It is through hole, right angle.
The contact material is copper alloy with gold plating, 10µin thickness.
-40°C to 105°C.
UL94 V-0.
