M24308/24-1P D-Sub connector plug with 9 male pins. Through-hole mounting with solder termination and gold contacts.
Mfr Part #:

M24308/24-1P

Available from 1 distributors
Mfr Name: Positronic
Positronic
D-Sub connector plug with 9 male pins. Through-hole mounting with solder termination and gold contacts.
✓ Total Stock: 21 pcs

M24308/24-1P Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
ADI/AAR OEM Supply ✓
Non-Authorised Inventory information
21 pcs
On Request
21 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

M24308/24-1P Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Style
Connector Type
Contact Finish
Contact Type
Current Rating (Amps)
Flange Feature
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Rows
Primary Material
Shell Size, Connector Layout
Termination
Termination Style
View Similar Products (0)

M24308/24-1P Description

Short technical summary and product information.

The M24308/24-1P is a D-Sub connector plug from Positronic. It features 9 positions arranged in 2 rows with male pins. The connector uses a through-hole mounting style and solder termination for secure attachment. The shell size is 1 (DE, E) with an unthreaded housing/shell flange. Contacts are signal type with gold plating for reliable conductivity. The primary material is metal, providing durability and EMI shielding. The insulator has a UL94 V-0 flammability rating. Electrically, the connector is rated for 7.5 A per contact. It is listed as RoHS3 compliant, REACH unaffected, and has an MSL of 1 (unlimited). This connector is suitable for standard D-Sub applications requiring a 9-pin interface.

M24308/24-1P Quick Information

Product Type: D-Sub Connector
Series: M24308
Canonical Name: D-Sub Connector Plug, 9 Position, Male Pins, Through Hole, Solder Termination, Gold Plated Contacts, Metal Shell
Subcategory: D-Sub Connector Assemblies

M24308/24-1P Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

M24308/24-1P Features

  • 9-position D-sub plug connector.
  • Gold-plated contacts for reliable signal.
  • Through-hole mounting with solder termination.
  • Rated current up to 7.5 A.
  • Metal shell for EMI shielding.

M24308/24-1P Applications

  • Used in data communication interfaces.
  • Ideal for industrial control systems.
  • Suitable for test and measurement equipment.
  • Common in serial port connections.

M24308/24-1P FAQs

6 frequently asked questions generated from this part’s specifications.
How many positions does this connector have?

9 positions.

What is the current rating of this connector?

7.5 A per contact.

What is the mounting type?

Through hole mounting with solder termination.

What contact finish is used?

Gold plated contacts.

What is the shell size?

Shell size 1 (DE, E).

Is this connector RoHS compliant?

Listed as RoHS3 compliant (unverified).
