| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20,000 pcs
|
20000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1,000 pcs
|
1000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Resistance | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Dielectric Withstanding Voltage | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Insulation Resistance | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style |
The Harwin M22-2031205 is a 12 position unshrouded pin header from the M22 series, designed for board-to-board interconnections. It features a 2.00mm pitch with a single row of square male pins terminated in a right angle through hole solder configuration.
Key specifications include a current rating of 1A per contact, gold contact finish on phosphor bronze contacts, and an operating temperature range of -55°C to +105°C. The insulation is molded from black polyamide (PA6T/Nylon 6T) with a UL94 V-0 flammability rating, and an insulation height of 2.00mm.
The header is unshrouded with a push-pull fastening type and is suitable for applications requiring a compact, low-profile interconnect. All 12 positions are loaded, providing full connectivity.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.93 | $0.93 |
| 10+ | $0.79 | $0.79 |
| 100+ | $0.67 | $0.67 |
| 500+ | $0.60 | $0.60 |
| 1,000+ | $0.57 | $0.57 |
| 2,500+ | $0.57 | $0.57 |
| 5,000+ | $0.51 | $0.51 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
12 positions.
2.00mm (0.079 inches).
Through hole, right angle solder termination.
1A per contact.
-55°C to +105°C.
Unshrouded.
