Mfr Part #:

M22-2010546

Name: M22-2010546
Brand: Harwin Inc.
SKU: M22-2010546

Mfr Name: Harwin Inc.

Description:

CONN HEADER VERT 5POS 2MM

Stock on Request

M22-2010546 Description

Short technical summary and product information.

CONN HEADER VERT 5POS 2MM

Mfr Standard Lead Time: 12 weeks (varies by distributor)

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Category	Headers, Male Pins
Manufacturer Name	Harwin Inc.
Connector Type	Header, Cuttable
Contact Finish	Tin
Contact Length	0.138" (3.50mm)
Contact Material	Phosphor Bronze
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	1A per Contact
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	0.059" (1.50mm)
Insulation Material	Polyamide (PA6T), Nylon 6T
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	5
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature	-55°C ~ 105°C
Overall Contact Length	0.331" (8.40mm)
Pitch	0.079" (2.00mm)
Shrouding	Unshrouded
Style	Board to Board
Termination	Solder
