Harwin M20-9760542 is a 10 position (5+5) dual row straight pin header from the M20 series. It features a 2.54mm (0.1") pitch and is designed for through hole mounting, making it suitable for board-to-board and cable interconnections.
The header is unshrouded with male pins, contact material is brass with a gold+tin finish. The insulator is black polyamide (PA6T) rated UL94 V-0. Electrical ratings include a current rating of 3A per contact, initial contact resistance of 20mΩ max, insulation resistance of 500MΩ min, and a dielectric withstanding voltage of 500V AC. Operating temperature range is -40°C to 105°C.
The connector is cuttable, allowing the user to break the header to a desired number of positions using the M20 Hand Cutting Tool. This provides flexibility in prototyping and design.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.42 | $0.42 |
| 10+ | $0.36 | $0.36 |
| 100+ | $0.31 | $0.31 |
| 250+ | $0.27 | $0.27 |
| 1,000+ | $0.26 | $0.26 |
| 2,500+ | $0.25 | $0.25 |
| 5,000+ | $0.23 | $0.23 |
| 10,000+ | $0.22 | $0.22 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The header has 10 positions arranged in a dual row (5+5).
The pitch is 2.54mm (0.1").
The current rating is 3A per contact.
Through hole (solder termination).
The contact finish is gold+tin.
The insulator is rated UL94 V-0.
Operating temperature range is -40°C to 105°C.
