| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4,000 pcs
|
4000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
6 pcs
|
6 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish - Mating | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| SVHC Present | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The Harwin M20-8760542 is a 10 position (5+5) dual row unshrouded male pin header from the M20 series, designed for 2.54mm (0.1") pitch applications. The connector features a straight (vertical) surface mount configuration with 5.8mm mating pin height. Contacts are made of brass with Gold finish on the mating area and Tin finish on termination, ensuring reliable connectivity and solderability.
The header is rated for 3A per contact and 250V, with an operating temperature range of -40°C to 105°C. The insulation is black polyamide (PA6T/Nylon 6T) with UL94 V-0 flammability rating. The unshrouded push-pull design allows for easy mating and unmating. This connector can be cut to a smaller number of positions using the Harwin M20 Hand Cutting Tool Z1022-00, providing flexibility for custom configurations.
It is suitable for board-to-board or board-to-cable interconnections in a variety of electronic assemblies. The surface mount termination enables efficient automated assembly. Packaging is loose (tray or tube). Compliance with RoHS and REACH is indicated but unverified.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.83 | $0.83 |
| 10+ | $0.71 | $0.71 |
| 100+ | $0.60 | $0.60 |
| 250+ | $0.60 | $0.60 |
| 500+ | $0.53 | $0.53 |
| 1,000+ | $0.50 | $0.50 |
| 5,000+ | $0.45 | $0.45 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The header has 10 positions (5+5 in dual row).
The pitch is 2.54mm (0.100").
The current rating is 3A per contact maximum.
The voltage rating is 250V.
The mounting type is Surface Mount (SMT).
The contact finish on the mating area is Gold, and the termination finish is Tin.
Yes, the header is cuttable and can be reduced to a smaller number of contacts using the Harwin M20 Hand Cutting Tool Z1022-00.
