Mfr Part #:

M20-8760246R

Name: M20-8760246R
Brand: Harwin Inc.
SKU: M20-8760246R

Mfr Name: Harwin Inc.

Description:

CONN HDR .100" TIN SMD 4POS

Stock on Request

M20-8760246R Description

Short technical summary and product information.

CONN HDR .100" TIN SMD 4POS

Mfr Standard Lead Time: 12 weeks (varies by distributor)

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Category	Headers, Male Pins
Manufacturer Name	Harwin Inc.
Connector Type	Header, Cuttable
Contact Finish	Tin
Contact Length	0.228" (5.80mm)
Contact Material	Brass
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	3A
Fastening Type	Push-Pull
Features	Pick and Place
Insulation Color	Black
Insulation Height	0.100" (2.54mm)
Insulation Material	Polyamide (PA6T), Nylon 6T
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount
Number of Positions	4
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature	-40°C ~ 105°C
Pitch	0.100" (2.54mm)
Row Spacing	0.100" (2.54mm)
Shrouding	Unshrouded
Style	Board to Board or Cable
Termination	Solder
Voltage Rating	250VAC/DC
