M20-7870442R The M20-7870442R is a double-row 8-position female receptacle with a 2.54mm pitch, designed for surface mount applications. It features push-pull fastening and gold-plated contacts.
Mfr Part #:

M20-7870442R

Available from 1 distributors
Mfr Name: Harwin Inc.
Harwin Inc.
The M20-7870442R is a double-row 8-position female receptacle with a 2.54mm pitch, designed for surface mount applications. It features push-pull fastening and gold-plated contacts.
✓ Total Stock: 8,000 pcs
$ Price Range: $0.79

M20-7870442R Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
AA2DE ✓
Non-Authorised Inventory information
8,000 pcs
On Request
8000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

M20-7870442R Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Type
Current Rating (Amps)
Fastening Type
Insulation Color
Insulation Height
Lead Spacing
Mated Stacking Heights
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
Row Spacing
Style
Tape & Reel
Termination
Voltage Rating
View Similar Products (0)

M20-7870442R Description

Short technical summary and product information.

The M20-7870442R is a 2.54mm pitch (0.100") female receptacle from Harwin's M20 series. It features an 8-position (4+4) double-row configuration with a straight SMT termination style. The connector offers a push-pull fastening mechanism and supports board-to-board and board-to-cable applications. The housing is black high-temperature thermoplastic, rated UL94 V-0, with an insulation height of 7.50mm. Mated stacking heights of 10.04mm and 11.63mm are available.



Electrical ratings include a current rating of 3A per contact and a voltage rating of 1000V. The operating temperature range is -40°C to 105°C. The contact finish is gold on the contact area and tin on the termination. The component is packaged in tape and reel for automated assembly.



This receptacle is suitable for use in a variety of electronic assemblies requiring reliable, space-saving connections. Its dual-entry design allows for both top and bottom entry, providing flexibility in PCB layout.

M20-7870442R Quick Information

Product Type: Receptacle Connector
Series: M20
Canonical Name: Harwin M20-7870442R 8 Position (4+4) Female Receptacle, 2.54mm Pitch, Surface Mount
Subcategory: Headers, Receptacles, Female Sockets

M20-7870442R Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

M20-7870442R Estimated Pricing

Qty Low High
5,200+ $0.79 $0.79

Estimated market price range - modelled values for guidance only, not live distributor offers.

M20-7870442R Features

  • 8-position dual-row SMT female receptacle.
  • 2.54mm pitch with 7.50mm insulation height.
  • Gold contact finish, tin termination finish.
  • Rated for 3A current and 1000V voltage.
  • Push-pull fastening for secure mating.

M20-7870442R Applications

  • Ideal for board-to-board interconnections.
  • Suitable for cable-to-board connections.
  • Used in stacked PCB configurations.
  • Works in compact surface mount designs.

M20-7870442R FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the M20-7870442R have?

8 positions (4+4 double-row).

What is the pitch of the M20-7870442R?

2.54mm (0.100 inches).

What is the current rating of the M20-7870442R?

3A per contact.

What is the voltage rating of the M20-7870442R?

1000V (manufacturer specified; note: datasheet mentions 500V AC dielectric withstanding voltage).

What is the mounting type of the M20-7870442R?

Surface mount (SMT).

What is the contact finish on the M20-7870442R?

Gold finish on the contact area and tin finish on the termination.

What is the operating temperature range of the M20-7870442R?

-40°C to 105°C.
