The Harwin M20-7860346 is a 3-position, single row female socket receptacle designed for board-to-board applications. It features a 2.54mm (0.100") pitch and accepts bottom or top entry mating. The connector uses push-pull fastening and is housed in a black insulator with a height of 7.50mm.
Electrical rating is 3A continuous current. The operating temperature range spans -40°C to 105°C, suitable for a wide variety of environments. The insulator material carries a UL94 V-0 flammability rating.
Termination is surface mount solder, making it compatible with standard SMD assembly processes. Mated stacking heights of 10.04mm and 11.63mm are supported. All 3 positions are loaded with tin-plated female socket contacts.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.50 | $0.50 |
| 10+ | $0.49 | $0.49 |
| 25+ | $0.37 | $0.37 |
| 73+ | $0.35 | $0.35 |
| 292+ | $0.32 | $0.32 |
| 1,022+ | $0.31 | $0.31 |
| 2,555+ | $0.30 | $0.30 |
| 5,037+ | $0.27 | $0.27 |
| 10,001+ | $0.26 | $0.26 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The M20-7860346 has 3 positions, all loaded, in a single row.
The pitch is 2.54mm (0.100").
The current rating is 3A.
The mounting type is surface mount with solder termination.
The operating temperature range is -40°C to 105°C.
The contact finish is tin.
