| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
32,292 pcs
|
32292 pcs | On Request | 1 | On Request | On Request | 10+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Average Forward Current | |
| Current | |
| Forward Voltage (Maximum @ IF=8 A, Tj=25 °C) | |
| Forward Voltage (Typical @ IF = 8 A, TJ = 150 °C) | |
| Halogen Free | |
| Junction Capacitance | |
| Junction to Ambient Thermal Resistance | |
| Junction to Case Thermal Resistance | |
| Lead Soldering Temperature | |
| Maximum Junction Temperature | |
| Mounting Type | |
| Operating Temperature | |
| Peak Repetitive Reverse Voltage | |
| Power Dissipation | |
| Reverse Current (Maximum @ VR = 600 V, Tj = 25 °C) | |
| Reverse Current (Typical @ VR = 600 V, TJ = 125 °C) | |
| Reverse Recovery (Maximum @ dI/dt = 200 A/μs, VR = 400 V, IF = 8 A, TJ = 125 °C) | |
| Reverse Recovery (Maximum @ dI/dt = 200 A/μs, VR = 400 V, IF = 8 A, TJ = 25 °C) | |
| Reverse Recovery Charge (Maximum @ dI/dt = 200 A/μs, VR = 400 V, IF = 8 A, TJ = 25 °C) | |
| Reverse Recovery Charge (Typical @ dI/dt = 200 A/μs, VR = 400 V, IF = 8 A, TJ = 125 °C) | |
| Reverse Recovery Current (Maximum @ dI/dt = 200 A/μs, VR = 400 V, IF = 8 A, TJ = 25 °C) | |
| Reverse Recovery Current (Typical @ dI/dt = 200 A/μs, VR = 400 V, IF = 8 A, TJ = 125 °C) | |
| Reverse Recovery Time (trr) | |
| Softness Factor (Typical @ dI/dt = 200 A/μs, VR = 400 V, IF = 8 A, TJ = 125 °C) | |
| Softness Factor (Typical @ dI/dt = 200 A/μs, VR = 400 V, IF = 8 A, TJ = 25 °C) | |
| Speed | |
| Storage Temperature | |
| Supplier Device Package | |
| Supplier Package | |
| Surge Current Rating (Maximum @ 60 Hz, ½ cycle) | |
| Surge Current Rating (Maximum @ ½ cycle of t = 28 μs Sinusoid, Tc = 25 °C) | |
| Technology | |
| Voltage |
The Power Integrations LXA08T600 is a high-performance PFC diode from the Qspeed™ X-Series family. It offers a 600V repetitive reverse voltage rating and an average forward current of 8A. This diode is designed with advanced silicon technology to achieve the lowest QRR of any 600V silicon diode, leading to increased efficiency, reduced EMI, and the elimination of snubbers.
Key electrical specifications include a typical forward voltage of 2.1V at 8A and 150°C, and a maximum forward voltage of 2.94V at 8A and 25°C. The reverse recovery time (trr) is as low as 34 ns at 25°C, with a reverse recovery charge (QRR) of 48 nC. Its high dIF/dt capability of 1000 A/μs enables extremely fast switching.
The LXA08T600 is housed in a TO-220AC package, suitable for through-hole mounting. It operates at a maximum junction temperature of 150°C and has a junction-to-case thermal resistance of 1.5 °C/W. The device is RoHS3 compliant, lead-free, and halogen-free.
Applications for this diode include Power Factor Correction (PFC) boost diodes, motor drive circuits, and DC-AC inverters. Its soft recovery characteristics and low reverse recovery parameters make it ideal for designs requiring high efficiency and reduced component count.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The peak repetitive reverse voltage rating is 600 V.
The average forward current is 8 A.
The typical forward voltage is 2.94 V at 8 A and 25 °C.
The reverse recovery time is 34 ns at 25 °C.
The LXA08T600 is supplied in a TO-220AC package.
Yes, the LXA08T600 is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
