LV2842XLVDDCR The Texas Instruments LV2842XLVDDCR is a PWM DC/DC buck regulator with an input voltage range of 4.5V to 42V and a maximum output current of 0.6A. It features a typical quiescent current of 1.3µA and operates over a wide temperature range.
