LTL57173HR The Lite-On Inc. LTL57173HR is a red rectangular LED light bar. It offers a typical luminous intensity of 4.2 mcd and a forward voltage of 2.6V.
Mfr Part #:

LTL57173HR

Available from 1 distributors
Mfr Name: Lite-On Inc.
Lite-On Inc.
The Lite-On Inc. LTL57173HR is a red rectangular LED light bar. It offers a typical luminous intensity of 4.2 mcd and a forward voltage of 2.6V.
✓ Total Stock: 180 pcs
$ Price Range: $0.99

LTL57173HR Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
180 pcs
On Request
180 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

LTL57173HR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Mounting Type
Operating Temperature Range
View Similar Products (0)

LTL57173HR Description

Short technical summary and product information.

The LTL-50000 series from Lite-On Inc. includes the LTL57173HR, a rectangular light bar designed for applications requiring a large, bright light source. This red LED light bar features a dominant wavelength of 623nm and a peak emission wavelength of 635nm.



With a typical luminous intensity of 4.2 mcd at 10mA, the LTL57173HR operates with a maximum continuous forward current of 25mA and a maximum forward voltage of 2.6V. The component has a power dissipation of 75mW per chip and a reverse voltage rating of 5V.



Designed for easy mounting on PC boards, this light bar is housed in a 5-pin DIP package. It operates within a temperature range of -35°C to +85°C. The LTL57173HR is suitable for panel and legend mount applications where excellent ON-OFF contrast and uniform light emission are required.

LTL57173HR Quick Information

Product Type: LED Light Bar
Series: LTL-50000 Series
Canonical Name: Lite-On Inc. LTL57173HR Rectangular Light Bar LED
Subcategory: Light Bar

LTL57173HR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

LTL57173HR Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

LTL57173HR Features

  • Red rectangular light bar LED.
  • Typical luminous intensity of 4.2 mcd.
  • Maximum forward voltage of 2.6V.
  • Continuous forward current of 25mA.
  • Through-hole mounting DIP package.

LTL57173HR Applications

  • Indicator for control panels.
  • Legend illumination applications.
  • General purpose light source.
  • Visual status signaling.

LTL57173HR FAQs

7 frequently asked questions generated from this part’s specifications.
What is the forward voltage of the LTL57173HR?

The maximum forward voltage is 2.6V at 20mA (2.8V from another source).

What is the operating temperature range?

-35°C to +85°C.

What is the package type?

Through-hole DIP package.

What is the typical luminous intensity?

4.2 mcd at 10mA (minimum 3.8 mcd).

What is the peak wavelength?

635 nm at 20mA.

What is the maximum continuous forward current?

25 mA.

What are the lens dimensions?

7.49 x 12.7 x 8 mm.
