| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
150 pcs
|
150 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| CCT (K) | |
| CRI (Color Rendering Index) | |
| Color | |
| Configuration | |
| Current | |
| Lens Type | |
| Lumens | |
| Luminous Flux @ Current | |
| Mounting Type | |
| Temperature | |
| Type | |
| Voltage |
This New Energy LSR2-08F04-5070-00 LED module is part of the OSLON Square platform, designed for rapid integration into LED lighting fixtures. It features a cool white light with a Correlated Color Temperature (CCT) of 5000K and a Color Rendering Index (CRI) of 70.
The module provides a nominal luminous flux of 2520 lumens at a 700mA current, with a nominal power consumption of 15.7W and an efficacy of 120 lm/W. It operates at a nominal voltage of 22.4V and has a nominal current of 700mA, with a maximum current of 1800mA.
With a rectangular configuration and dimensions of 59.59mm in length and 45.01mm in width, this LED module is suitable for various lighting applications. It has a flat lens type and an operating temperature of 85°C. The module is RoHS3 compliant and has an MSL rating of 1.
Designed for superior performance and flexibility, these modules can be configured with off-the-shelf optics and drivers. They are ideal for applications such as canopy lighting, garages, high bays, streetlights, and architectural lighting.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The CCT is 5000K.
The CRI is 70.
The nominal luminous flux at 700mA is 2520lm.
The nominal power consumption is 15.7W.
The dimensions are 59.59mm L x 45.01mm W.
The operating temperature is 85°C.
Yes, it is RoHS3 Compliant.
