| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
218 pcs
|
218 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Current | |
| Features | |
| Form | |
| Industrial Grade | |
| Insulation Resistance | |
| Lead Style | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Storage Temperature | |
| Tape & Reel | |
| Type | |
| Voltage |
The Littelfuse LSP05G277PX3333 is a Type 2 Surge Protection Device (SPD) designed for LED lighting applications. It is rated for a maximum AC voltage of 320VAC and a continuous current of 10A. The device provides surge protection with a maximum discharge current of 10kA (8/20µs waveform) and a nominal discharge current of 5kA.
This SPD uses thermally protected varistor technology and is housed in a screw-mount module. It features an insulation resistance greater than 1,000 MΩ and an isolation voltage of 600V when the thermal disconnect opens. The operating temperature range is -45°C to +85°C, with storage from -45°C to +90°C.
The module is UL1449 recognized and meets IEC 61643-11 Class II and EN 61643-11 Type 2 standards. It is RoHS compliant and suitable for outdoor and commercial LED lighting, roadway lighting, traffic lighting, digital signage, and flood lighting applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $11.52 | $11.52 |
| 10+ | $8.78 | $8.78 |
| 30+ | $8.34 | $8.34 |
| 105+ | $8.33 | $8.33 |
| 255+ | $8.28 | $8.28 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum AC voltage is 320VAC, with a nominal operating voltage of 277VAC.
The maximum discharge current is 10kA (8/20µs waveform).
The operating temperature range is -45°C to +85°C.
It uses screw mounting and is a module-only form factor.
Yes, the datasheet states it is RoHS compliant.
It meets IEC 61643-11 Class II, EN 61643-11 Type 2, and ANSI C136.2 Enhanced Level.
The continuous current rating is 10A.
