| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
98 pcs
|
98 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Current | |
| Features | |
| Form | |
| Form Factor | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Standards | |
| Storage Temperature | |
| Tape & Reel | |
| Type | |
| Voltage |
The Littelfuse LSP05240P is a single-pole surge protection module from the LSP05 series, designed for LED lighting and other outdoor applications. It is rated for a maximum continuous operating voltage of 240 VAC and provides a nominal discharge current of 5 kA (8/20 μs waveform) with a maximum discharge current of 10 kA.
The module uses thermally protected varistor technology and is parallel-connected. It features an IP66 rating for dust and water ingress protection, making it suitable for harsh environments. The operating temperature range is -45°C to 85°C, with a storage range of -45°C to 125°C.
Mechanical specifications include screw mounting and a compact form factor (48x48x30mm). The device is compliant with UL1449 Type 4CA, IEC61643-11 Class II, EN61643-11 Type 2, IEEE C62.41.2, ANSI C82.77-5-2015, and US DOE MSSLC standards. Agency approvals include CE, cURus, and UL.
| Qty | Low | High |
|---|---|---|
| 1+ | $16.07 | $16.07 |
| 8+ | $12.33 | $12.33 |
| 104+ | $11.92 | $11.92 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
240 VAC.
Nominal discharge current is 5 kA and maximum discharge current is 10 kA, both with an 8/20 μs waveform.
-45°C to 85°C.
IP66.
Yes, it is RoHS3 compliant.
UL1449 Type 4CA, IEC61643-11 Class II, EN61643-11 Type 2, IEEE C62.41.2, ANSI C82.77-5-2015, and US DOE MSSLC.
Screw mounting.
