LSHM-150-02.5-L-DV-A-S-K-TR Samtec LSHM-150-02.5-L-DV-A-S-K-TR is a 100-position, 2-row, 0.50mm pitch self-mating hermaphroditic connector for board-to-board mezzanine applications. It features surface mount termination, gold-plated contacts, and a shielded design with a pick-and-place pad.
Mfr Part #:

LSHM-150-02.5-L-DV-A-S-K-TR

Available from 2 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
Samtec LSHM-150-02.5-L-DV-A-S-K-TR is a 100-position, 2-row, 0.50mm pitch self-mating hermaphroditic connector for board-to-board mezzanine applications. It features surface mount termination, gold-plated contacts, and a shielded design with a pick-and-place pad.
✓ Total Stock: 130 pcs
$ Price Range: $6.09 - $8.34

LSHM-150-02.5-L-DV-A-S-K-TR Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
65 pcs
On Request
65 pcs On Request 1 On Request On Request On Request On Request On Request
RAD ✓
Non-Authorised Inventory information
65 pcs
On Request
65 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

LSHM-150-02.5-L-DV-A-S-K-TR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Material
Current Rating
Features
Height Above Board
Insulator Material
Mated Stacking Heights
Mounting Type
Number of Positions
Number of Rows
Operating Temperature Range
Pitch
Tape & Reel
Voltage Rating
View Similar Products (0)

LSHM-150-02.5-L-DV-A-S-K-TR Description

Short technical summary and product information.

The Samtec LSHM-150-02.5-L-DV-A-S-K-TR is a high-density, self-mating hermaphroditic connector from the Razor Beam series, designed for parallel board-to-board mezzanine stacking. It offers 100 positions arranged in 2 rows on a 0.50mm pitch, enabling compact and reliable interconnects in space-constrained designs.



This connector supports multiple mated stacking heights of 5mm, 5.5mm, 6.5mm, and 8.5mm, providing flexibility for various board spacing requirements. It is rated for 2.0A per pin and 160VAC/226VDC, with an operating temperature range of -55°C to +125°C. The contacts are phosphor bronze with 10µin gold plating, ensuring robust signal integrity and corrosion resistance.



The LSHM-150-02.5-L-DV-A-S-K-TR includes a board guide, pick-and-place pad, and shielding for enhanced EMI protection. It is packaged in tape and reel for automated assembly and is lead-free solderable. The insulator is black LCP, and the part is RoHS3 compliant and REACH unaffected.

LSHM-150-02.5-L-DV-A-S-K-TR Quick Information

Product Type: Board-to-Board Connector
Series: Razor Beam
Canonical Name: Samtec LSHM Series 100-Position (2 Rows) 0.50mm Pitch Self-Mating Hermaphroditic Connector, Surface Mount, Gold 10µin Contacts, Shielded, with Pick & Place Pad, Tape & Reel
Subcategory: Mezzanine Connector

LSHM-150-02.5-L-DV-A-S-K-TR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Lead-Free Solderable

LSHM-150-02.5-L-DV-A-S-K-TR Estimated Pricing

Qty Low High
1+ $8.34 $8.34
10+ $7.09 $7.09
25+ $6.65 $6.65
50+ $6.33 $6.33
100+ $6.09 $6.09
575+ $6.09 $6.09

Estimated market price range - modelled values for guidance only, not live distributor offers.

LSHM-150-02.5-L-DV-A-S-K-TR Features

  • 100 positions in 2 rows at 0.50mm pitch.
  • Self-mating hermaphroditic connector design.
  • Rated for 2.0A per pin and 160VAC/226VDC.
  • Supports multiple mated stacking heights.
  • Shielded with pick-and-place pad for SMT.

LSHM-150-02.5-L-DV-A-S-K-TR Applications

  • Board-to-board mezzanine stacking applications.
  • High-density interconnect in compact electronics.
  • Parallel stacking with 5mm to 8.5mm spacing.
  • Automated SMT assembly with pick-and-place.

LSHM-150-02.5-L-DV-A-S-K-TR FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the LSHM-150-02.5-L-DV-A-S-K-TR have?

It has 100 positions arranged in 2 rows.

What is the pitch of this connector?

The pitch is 0.50mm (0.020").

What is the current rating per pin?

The current rating is 2.0A per pin.

What is the voltage rating?

The voltage rating is 160VAC / 226VDC.

What mounting type does this connector use?

It is surface mount (SMT).

What is the operating temperature range?

The operating temperature range is -55°C to +125°C.

What mated stacking heights are supported?

Supported mated stacking heights are 5mm, 5.5mm, 6.5mm, and 8.5mm.
