LSA67K This ams-OSRAM LS A67K-J1K2-1-0-2-R33-Z is a red LED indicator with a 1.8V forward voltage and 630nm dominant wavelength. It is supplied in a 2-SMD, Boomerang package.
Mfr Part #:

LSA67K

Available from 2 distributors
Mfr Name: Osram
Osram
This ams-OSRAM LS A67K-J1K2-1-0-2-R33-Z is a red LED indicator with a 1.8V forward voltage and 630nm dominant wavelength. It is supplied in a 2-SMD, Boomerang package.
✓ Total Stock: 161,809 pcs
$ Price Range: $0.99

LSA67K Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
ACK ELEKTRONIK ✓
Non-Authorised Inventory information
161,232 pcs
On Request
161232 pcs On Request 1 On Request On Request On Request On Request On Request
Chanetech ✓
Non-Authorised Inventory information
577 pcs
On Request
577 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

LSA67K Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Configuration
Height (Max)
Lens Color
Lens Size
Lens Style
Lens Transparency
Millicandela Rating
Mounting Type
Supplier Device Package
Viewing Angle
View Similar Products (0)

LSA67K Description

Short technical summary and product information.

The ams-OSRAM LS A67K-J1K2-1-0-2-R33-Z is a red LED indicator designed for discrete applications. It operates at a typical forward voltage of 1.8V and has a dominant wavelength of 630nm, with a peak wavelength of 643nm. The luminous intensity is rated at 7.85mcd with a wide viewing angle of 120°.



This component features a clear, colorless lens with a round, flat-top style, measuring 2.40mm in diameter. It is housed in a 2-SMD, Boomerang package suitable for surface mounting in a right-angle configuration. The dimensions of the package are 4.00mm in length and 3.60mm in width, with a maximum height of 4.20mm.



Designed for reliability, this LED indicator has a Moisture Sensitivity Level (MSL) of 1 and is RoHS3 compliant. It is part of the SIDELED® series, offering a standard configuration for various electronic indications.

LSA67K Quick Information

Product Type: LED Indicator
Series: SIDELED®
Canonical Name: ams-OSRAM LS A67K-J1K2-1-0-2-R33-Z LED Red Indicator
Subcategory: LED Indication - Discrete

LSA67K Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

LSA67K Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

LSA67K Features

  • Red LED indicator with 630nm dominant wavelength.
  • 1.8V typical forward voltage.
  • 120° wide viewing angle.
  • Surface mount, right angle package.
  • 2-SMD, Boomerang package type.

LSA67K Applications

  • Used in indicator lighting systems
  • Suitable for signaling applications
  • Ideal for compact electronic devices
  • Employed in optical sensing projects

LSA67K FAQs

5 frequently asked questions generated from this part’s specifications.
What is the forward voltage of the LS A67K-J1K2-1-0-2-R33-Z LED?

The typical forward voltage for the LS A67K-J1K2-1-0-2-R33-Z LED is 1.8V.

What is the dominant wavelength of this red LED?

The dominant wavelength of this red LED is 630nm.

What is the viewing angle of the ams-OSRAM LS A67K-J1K2-1-0-2-R33-Z?

The viewing angle of the ams-OSRAM LS A67K-J1K2-1-0-2-R33-Z is 120°.

What type of package is the LS A67K-J1K2-1-0-2-R33-Z supplied in?

The LS A67K-J1K2-1-0-2-R33-Z is supplied in a 2-SMD, Boomerang package.

How should the LS A67K-J1K2-1-0-2-R33-Z be mounted?

The LS A67K-J1K2-1-0-2-R33-Z should be surface mounted in a right-angle configuration.
