The Bel Power Solutions LS1601-9EP is an enclosed AC/DC converter designed for ITE (Commercial) and Railway applications. It offers a power output of 101W with a 24V output voltage and an efficiency of 85%.
Key electrical specifications include a wide input voltage range of 85 to 264 VAC or 88 to 372 VDC. The converter provides adjustable output voltage and supports remote on/off control. It has a single output and an isolation voltage rating of 2 kV.
Mechanically, the LS1601-9EP is a chassis mount unit with dimensions of 168.0mm x 111.0mm x 60.0mm. It operates within a temperature range of -40°C to 71°C. The converter is conformal coated for added protection.
Compliance includes RoHS3, MSL 1, and REACH Unaffected, though these are noted with low confidence due to verification status.
85 ~ 264 VAC or 88 ~ 372 VDC.
Enclosed, conformal coated with chassis mount.
-40°C to 71°C.
24V.
4.2 A.
101W.
Adjustable Output, Remote On/Off, Universal Input.
