The Morning Star Industrial LS15-23B24DR3 is a 15W AC DC converter designed for various applications, including household appliances and ITE (Commercial) equipment. It provides a stable 24V output with a current rating of 625mA.
This converter operates with a wide input voltage range of 85 to 305 VAC or 100 to 430 VDC, ensuring flexibility in different power environments. It boasts an efficiency of 84% and a single output.
The LS15-23B24DR3 is designed for Through Hole mounting and comes in a 6-SIP Module package. It operates within an extended temperature range of -40°C to 85°C, with derating applied at higher temperatures. The dimensions are 33.4mm in length, 9.7mm in width, and 21.5mm in height.
Compliance standards include 60335-1 and 62368-1. The RoHS status is RoHS3 Compliant, and the Moisture Sensitivity Level is 1 Unlimited.
The input voltage range is 85-305 VAC and 100-430 VDC.
The output voltage is 24V at 625mA.
The operating temperature range is -40°C to 85°C with derating.
It comes in a 6-SIP Module with Through Hole mounting.
The power rating is 15W.
It complies with standards 60335-1 and 62368-1.
