The Mornsun LS15-23B03DR3 is a 9.9W AC/DC converter designed for various applications including household appliances and ITE commercial use. It features an ultra-wide input voltage range of 85-305VAC and 100-430VDC, accepting either AC or DC input.
This converter provides a single output of 3.3V at 3A, with a rated efficiency of 78% at 230VAC. It boasts high I/O isolation of up to 4000VAC, making it suitable for applications requiring robust isolation. The operating ambient temperature range is -40℃ to +85℃, with derating as necessary.
Packaged in a 6-SIP module for through-hole mounting, the LS15-23B03DR3 has dimensions of 33.4mm x 9.7mm x 21.5mm. It meets safety standards such as 60335-1 and 62368-1, and is RoHS3 compliant.
The input voltage range is 85-305 VAC or 100-430 VDC.
The output is 3.3 VDC at 3A.
The operating temperature range is -40°C to +85°C.
The package is a 6-SIP Module with through-hole mounting.
The input-to-output isolation voltage is 4000 VAC.
The dimensions are 33.4mm x 9.7mm x 21.5mm (length x width x height).
The efficiency is 78%.
