| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| No Load Power Consumption | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Mean Well LRS-50-12 is an enclosed AC/DC power supply designed for various applications, including household appliances and ITE commercial equipment. It delivers a stable 12Vdc output at a maximum current of 4.2A, with a total power rating of 50W.
This power supply operates with a wide input voltage range of 85~264Vac, ensuring compatibility across different power grids. It boasts a high efficiency of 86% and a low no-load power consumption of less than 0.2W. The unit is designed for chassis mounting and features adjustable output and universal input capabilities.
Thermal management is handled through free air convection, with an operating temperature range of -30°C to +70°C, including derating. The LRS-50-12 also includes a 300Vac surge input withstand capability for 5 seconds, enhancing its robustness.
Key compliance and safety standards include CB, CCC, CE, cURus, and TUV certifications. The dimensions are 99.0mm x 82.0mm x 30.0mm.
The LRS-50-12 provides a 12Vdc output voltage at a maximum current of 4.2 Amps.
The maximum power output for the LRS-50-12 is 50 Watts.
The LRS-50-12 accepts an input voltage range of 85 to 264Vac.
The LRS-50-12 can operate in temperatures ranging from -30°C to +70°C, with derating.
The LRS-50-12 is designed for chassis mounting.
Key features include adjustable output, universal input, and a low no-load power consumption of less than 0.2W.
