The Mean Well LPF-40D-15 is a 40W AC/DC LED driver designed for constant current output applications. It operates from a wide input voltage range of 90 to 305 VAC, offering flexibility for various power systems.
This LED driver boasts an efficiency of up to 89% and features a fanless design, allowing operation within a case temperature range of -40 to +80°C under free air convection. The IP67 rating ensures protection against dust and water ingress, making it suitable for dry, damp, or wet locations, both indoors and outdoors.
Key features include built-in active PFC, Class II power unit design, and a 3-in-1 dimming function for design flexibility in LED lighting systems. With a typical lifetime exceeding 50,000 hours and a 5-year warranty, the LPF-40D-15 is a reliable choice for LED panel lighting, downlights, decorative lighting, tunnel lighting, and moving signs.
90~305 VAC.
-40°C to +80°C.
IP67.
Up to 89%.
Yes, 3-in-1 dimming (0-10V, PWM, or resistor).
5 years.
12~54V.
