The MEAN WELL LPF-40-48 is an LED driver designed for versatile applications, offering a maximum power output of 40 Watts. It features a constant voltage (CV) mode with a 48Vdc output and a maximum current of 0.84 Amps, also functioning in constant current (CC) mode at 0.84 Amps. The device accepts a wide input voltage range from 90 to 305 Vac, making it suitable for global use.
With an operating temperature range of -40°C to +70°C, the LPF-40-48 is built to withstand demanding environmental conditions. It boasts an IP67 rating, indicating protection against dust and water ingress. This LED driver is compliant with UL8750 standards for LED power supplies and features Class II AC input, meaning it does not require a ground connection.
Designed for reliability and efficiency, this LED driver is an excellent choice for various lighting projects requiring stable power delivery. Its robust construction and wide operating parameters ensure consistent performance in diverse settings.
The input voltage range is 90~305 Vac.
IP67.
-40 to +70 °C.
48 Vdc at 0.84 A in both CV and CC modes.
40 W.
Yes, it supports both CV and CC modes.
China.
