| Category | |
| Manufacturer Name | |
| Board Type | |
| Contents | |
| Core Processor | |
| Mounting Type | |
| Number of I/O | |
| Platform | |
| Type | |
| Utilized IC |
The LPC845-BRK is an evaluation board from NXP Semiconductors designed for the LPC84x series of 32-bit ARM Cortex-M0+ microcontrollers. It operates at CPU frequencies up to 30 MHz and includes up to 64 KB of flash memory and 16 KB of SRAM. The board provides access to 54 general-purpose I/O pins, a 12-bit ADC, a 10-bit DAC, and 25 DMA channels.
Communication interfaces include four I2C channels, up to five USARTs, and two SPI interfaces. The board also supports a capacitive touch interface and features a switch matrix for flexible I/O configuration. The evaluation platform is intended for use with the MCUXpresso development environment.
The board is a fixed mounting type and comes with the board only. Note that the supplied datasheet is for the LPC84x MCU, not the evaluation board itself. Additional documentation such as a board-specific user manual may be required for full design details.
| Qty | Low | High |
|---|---|---|
| 1+ | $7.35 | $7.35 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The board is based on the ARM Cortex-M0+ core.
The maximum CPU frequency is 30 MHz.
The board supports up to 64 KB of flash memory and 16 KB of SRAM.
It provides up to 54 general-purpose I/O pins.
It includes up to 4 I2C, up to 5 USART, and up to 2 SPI interfaces.
Yes, it includes a capacitive touch interface.
The listed RoHS status is RoHS3 Compliant, but this is unverified.
