LPC812M101JTB16X The NXP Semiconductors LPC812M101JTB16X is a 32-bit microcontroller featuring an ARM Cortex-M0+ processor running at up to 30 MHz. It offers 16 kB of flash memory and 4 kB of SRAM.
Mfr Part #:

LPC812M101JTB16X

Available from 2 distributors
Mfr Name: NXP Semiconductors
NXP Semiconductors
The NXP Semiconductors LPC812M101JTB16X is a 32-bit microcontroller featuring an ARM Cortex-M0+ processor running at up to 30 MHz. It offers 16 kB of flash memory and 4 kB of SRAM.
✓ Total Stock: 3,687 pcs

LPC812M101JTB16X Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Xingangxin ✓
Non-Authorised Inventory information
3,667 pcs
On Request
3667 pcs On Request 1 On Request On Request On Request On Request On Request
Bristol Electronics ✓
Non-Authorised Inventory information
20 pcs
On Request
20 pcs On Request 1 On Request On Request 2026-02-25 06:16:38 On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

LPC812M101JTB16X Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connectivity
Core Processor
Core Size
Mounting Type
Number of I
Operating Temperature
Oscillator Type
Peripherals
Program Memory Size
Program Memory Type
RAM Size
Speed
Supplier Device Package
Supplier Package
Voltage
View Similar Products (0)

LPC812M101JTB16X Description

Short technical summary and product information.

The NXP Semiconductors LPC812M101JTB16X is a low-cost, 32-bit microcontroller based on the ARM Cortex-M0+ processor, operating at CPU frequencies up to 30 MHz. This MCU family supports up to 16 kB of flash programming memory and 4 kB of SRAM.



The peripheral set includes a CRC engine, one I2C-bus interface, up to three USARTs, up to two SPI interfaces, a multi-rate timer, a self-wake-up timer, and a state-configurable timer. It also features one comparator, function-configurable I/O ports via a switch matrix, an input pattern match engine, and up to 18 general-purpose I/O pins.



Designed for embedded applications, the LPC812M101JTB16X provides essential features like a system tick timer and Serial Wire Debug (SWD) support. The device operates within a voltage range of 1.8V to 3.6V and has an operating temperature range of -40°C to 105°C (TA).



This microcontroller is supplied in a 16-XSON surface mount package, with a package description of 16-XFDFN. Its compact size and integrated peripherals make it suitable for various embedded control tasks.

LPC812M101JTB16X Quick Information

Product Type: Microcontroller
Series: LPC81xM
Canonical Name: NXP Semiconductors LPC812M101JTB16X 32-bit ARM Cortex-M0+ Microcontroller
Subcategory: 32-bit ARM Cortex-M0+

LPC812M101JTB16X Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

LPC812M101JTB16X Features

  • 32-bit ARM Cortex-M0+ processor core.
  • Operates at CPU frequencies up to 30 MHz.
  • 16 kB on-chip flash programming memory.
  • 4 kB SRAM for data storage.
  • Integrated I2C, SPI, and UART serial interfaces.

LPC812M101JTB16X Applications

  • Suitable for general embedded control.
  • Ideal for low-power applications.
  • Used in compact electronic devices.
  • Applications requiring flexible I/O.

LPC812M101JTB16X FAQs

7 frequently asked questions generated from this part’s specifications.
What is the core processor of the LPC812M101JTB16X?

The core processor is an ARM Cortex-M0+.

What is the operating speed of this microcontroller?

The microcontroller operates at CPU frequencies of up to 30 MHz.

How much flash memory does the LPC812M101JTB16X have?

It has up to 16 kB of on-chip flash programming memory.

What is the SRAM size for this MCU?

The RAM size is 4 kB.

What are the available serial interfaces on this device?

The available serial interfaces are I2C, SPI, and UART/USART.

What is the operating temperature range?

The operating temperature range is -40°C to 105°C (TA).

What package is the LPC812M101JTB16X supplied in?

It is supplied in a 16-XSON package.
