Mfr Part #:

LPC810M021FN8

The NXP Semiconductors LPC810M021FN8 is a 32-bit microcontroller featuring an ARM Cortex-M0+ core. It operates at up to 30MHz and is housed in an 8-DIP package.

✓ Total Stock: 5,452 pcs

LPC810M021FN8 Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Flip Electronics ✓ Non-Authorised Inventory information	5,452 pcs On Request	5452 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

LPC810M021FN8 Description

Short technical summary and product information.

The LPC810M021FN8 from NXP Semiconductors is a 32-bit microcontroller based on the ARM Cortex-M0+ processor, capable of operating at CPU frequencies up to 30 MHz. This low-cost MCU family offers up to 4 kB of flash memory and 1 kB of SRAM.

Key peripherals include a CRC engine, one I2C-bus interface, USART, SPI interfaces, a multi-rate timer, self wake-up timer, and state-configurable timer. It also features a comparator and function-configurable I/O ports through a switch matrix, with up to 6 general-purpose I/O pins.

Designed for embedded applications, the LPC810M021FN8 supports a voltage range of 1.8V to 3.6V and operates within a temperature range of -40°C to 85°C. The microcontroller is available in an 8-DIP (0.300", 7.62mm) through-hole package, making it suitable for various board designs.

This device includes essential peripherals like Brown-out Detect/Reset, POR, PWM, and WDT, along with an internal oscillator. Its connectivity options include I2C, SPI, and UART/USART interfaces.

LPC810M021FN8 Quick Information

Product Type: Microcontroller

Canonical Name: LPC810M021FN8 32-bit ARM Cortex-M0+ Microcontroller

Subcategory: 32-bit Microcontroller

LPC810M021FN8 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

LPC810M021FN8 Features

32-bit ARM Cortex-M0+ core processor.
Operates at CPU frequencies up to 30 MHz.
4KB of on-chip flash programming memory.
1KB of SRAM.
8-DIP through-hole package.

LPC810M021FN8 Applications

Suitable for general embedded control tasks.
Ideal for applications requiring low power consumption.
Used in devices needing basic serial communication.
Applications with limited space for components.

LPC810M021FN8 FAQs

7 frequently asked questions generated from this part’s specifications.

What is the operating voltage range for the LPC810M021FN8?

The operating voltage range is 1.8V to 3.6V.

What package type is the LPC810M021FN8 microcontroller supplied in?

The LPC810M021FN8 is supplied in an 8-DIP (0.300", 7.62mm) through-hole package.

What is the operating temperature range for this microcontroller?

The operating temperature range is -40°C to 85°C (TA).

What is the program memory size and type for the LPC810M021FN8?

It has a program memory size of 4KB (4K x 8) of FLASH type.

What is the RAM size of the LPC810M021FN8?

The RAM size is 1K x 8.

What core processor does the LPC810M021FN8 use?

It uses an ARM Cortex-M0+ core processor.

What are the main connectivity interfaces on the LPC810M021FN8?

The main connectivity interfaces are I2C, SPI, and UART/USART.

Category	Microcontrollers
Manufacturer Name	NXP Semiconductors
Connectivity	I²C, SPI, UART/USART
Core Processor	ARM Cortex-M0+
Core Size	32-Bit
Lead Spacing	7.62 mm
Mounting Type	Through Hole
Number of I	6
Operating Temperature	[{'min': -40, 'max': 85, 'unit': '°C', 'display_value': '-40°C ~ 85°C'}]
Oscillator Type	Internal
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Size	4KB
Program Memory Type	FLASH
RAM Size	1KB
Speed	30 MHz
Supplier Device Package	8-DIP
Tape & Reel	No
Voltage	[{'min': 1.8, 'max': 3.6, 'unit': 'V', 'display_value': '1.8V ~ 3.6V'}]
