LPC5534JBD64K The NXP Semiconductors LPC5534JBD64K is a 32-bit microcontroller based on the ARM Cortex-M33 core, operating at up to 150 MHz. It features 128KB of flash memory and 96KB of SRAM.
Mfr Part #:

LPC5534JBD64K

Available from 1 distributors
Mfr Name: NXP Semiconductors
NXP Semiconductors
The NXP Semiconductors LPC5534JBD64K is a 32-bit microcontroller based on the ARM Cortex-M33 core, operating at up to 150 MHz. It features 128KB of flash memory and 96KB of SRAM.
✓ Total Stock: 16,000 pcs

LPC5534JBD64K Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Flip Electronics ✓
Non-Authorised Inventory information
16,000 pcs
On Request
16000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

LPC5534JBD64K Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connectivity
Core Processor
Core Size
Data Converters
Frequency
Mounting Type
Number of I
Operating Temperature
Oscillator Type
Peripherals
Program Memory Size
Program Memory Type
RAM Size
Speed
Supplier Device Package
Tape & Reel
USB
Voltage
View Similar Products (0)

LPC5534JBD64K Description

Short technical summary and product information.

The LPC5534JBD64K from NXP Semiconductors is an ARM Cortex-M33 based microcontroller designed for embedded applications. It operates at a frequency of up to 150 MHz and includes integrated DSP instructions and an FPU.



This microcontroller offers up to 128 KB of on-chip flash program memory and up to 96 KB of SRAM. It supports various peripherals including DMA, PWM, WDT, CAN FD, and multiple Flexcomm interfaces configurable as USART, SPI, I2C, or I2S. It also features a 13-channel 16-bit ADC and a 1-channel 12-bit DAC.



The LPC5534JBD64K is available in a 64-HTQFP (10x10) surface mount package. It operates within a voltage range of 1.8V to 3.6V and has an operating temperature range of -40°C to 105°C (TA).



Key features include crystal-less USB Full-Speed device and host capabilities, an internal oscillator, and a ROM bootloader supporting various programming interfaces.

LPC5534JBD64K Quick Information

Product Type: Microcontroller
Canonical Name: LPC5534JBD64K ARM Cortex-M33 Microcontroller
Subcategory: Embedded

LPC5534JBD64K Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

LPC5534JBD64K Features

  • ARM Cortex-M33 core running at 150 MHz.
  • 128KB on-chip flash program memory.
  • 96KB SRAM for data storage.
  • Rich peripheral set including CAN FD and Flexcomm.
  • 64-HTQFP surface mount package.

LPC5534JBD64K Applications

  • Suitable for embedded control applications.
  • Ideal for systems requiring CAN FD communication.
  • Supports flexible serial communication needs.
  • Features integrated DSP capabilities.

LPC5534JBD64K FAQs

4 frequently asked questions generated from this part’s specifications.
What is the operating voltage for the LPC5534JBD64K?

The operating voltage is 1.8V to 3.6V.

What package type is the LPC5534JBD64K available in?

It is available in a 64-HTQFP (10x10) surface mount package.

What is the operating temperature range for this microcontroller?

The operating temperature range is -40°C to 105°C (TA).

What is the RoHS status of the LPC5534JBD64K?

The RoHS status is RoHS3 Compliant.
