The LMH6642MFX is a high-speed operational amplifier designed for demanding applications. It features a wide bandwidth of 130 MHz and a fast slew rate of 135 V/µs, making it suitable for signal processing and amplification tasks.
This amplifier operates from a supply voltage range of 2.7 V to 12.8 V and provides a rail-to-rail output. With a typical quiescent current of 2.7 mA per channel and an output current capability of 115 mA, it balances performance with power efficiency.
The LMH6642MFX is available in SOIC and SOT-23 packages, supporting surface mount assembly. Its operating temperature range is -40°C to 85°C, ensuring reliable performance in various environmental conditions.
Key electrical characteristics include a typical gain bandwidth product of 57 MHz and low noise voltage density of 17 nV/√Hz. It also offers a typical common-mode rejection ratio of 95 dB.
The bandwidth at unity gain (Acl) for the LMH6642MFX is 130 MHz.
The typical slew rate for the LMH6642MFX is 135 V/µs.
The LMH6642MFX operates with a total supply voltage range from 2.7 V to 12.8 V.
The typical quiescent current per channel for the LMH6642MFX is 2.7 mA.
The LMH6642MFX has an operating temperature range of -40°C to 85°C.
The LMH6642MFX is available in SOIC (D) and SOT-23 (DBV) package types.
