LMH0387SLE/NOPB The Texas Instruments LMH0387SLE/NOPB is a specialized interface IC designed for 3G HD/SD SDI applications. It functions as a configurable I/O adaptive cable equalizer and cable driver.
Mfr Part #:

LMH0387SLE/NOPB

Available from 2 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments LMH0387SLE/NOPB is a specialized interface IC designed for 3G HD/SD SDI applications. It functions as a configurable I/O adaptive cable equalizer and cable driver.
✓ Total Stock: 3,314 pcs
$ Price Range: $15.78

LMH0387SLE/NOPB Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Xingangxin ✓
Non-Authorised Inventory information
3,314 pcs
On Request
3314 pcs On Request 1 On Request On Request On Request On Request On Request
HK XINYUANXIN ELECTRONIC TECH LIMITED ✓
Non-Authorised Inventory information
On Request
On Request
On Request On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

LMH0387SLE/NOPB Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Interface
Lead Spacing
Mounting Type
Operating Temperature
Package Quantity
Supplier Device Package
Supplier Package
Voltage
View Similar Products (0)

LMH0387SLE/NOPB Description

Short technical summary and product information.

The Texas Instruments LMH0387SLE/NOPB is a high-performance integrated circuit designed for Serial Digital Interface (SDI) applications, supporting 3G HD/SD standards. This device acts as a configurable I/O adaptive cable equalizer and cable driver, crucial for maintaining signal integrity over long cable runs.



Key electrical specifications include data rates ranging from 125Mbps to 2.97Gbps when receiving and DC to 2.97Gbps when driving a cable. It offers significant cable equalization capabilities, supporting up to 120 meters of Belden 1694A cable at 2.97Gbps, 200 meters at 1.485Gbps, and 400 meters at 270Mbps. The IC operates on a single 3.3V supply and features internally terminated 100Ω LVDS receiver outputs with programmable common mode voltage and swing.



This component is compliant with ST 424, ST 292, ST 344, and ST 259 standards, and also supports DVB-ASI at 270Mbps. It includes features like integrated return loss networks, power saving modes, and selectable slew rates for the cable driver. The device is housed in a 48-pin laminate TLGA package, suitable for surface mounting.



The operating temperature range for the LMH0387SLE/NOPB is from -40°C to 85°C, making it suitable for industrial environments. It also features programmable launch amplitude optimization and cable length indication.

LMH0387SLE/NOPB Quick Information

Product Type: Interface IC
Canonical Name: LMH0387SLE/NOPB 3G HD/SD SDI Configurable I/O Adaptive Cable Equalizer/Cable Driver
Subcategory: Configurable I/O Adaptive Cable Equalizer/Cable Driver

LMH0387SLE/NOPB Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

LMH0387SLE/NOPB Estimated Pricing

Qty Low High
1+ $15.78 $15.78

Estimated market price range - modelled values for guidance only, not live distributor offers.

LMH0387SLE/NOPB Features

  • 3G HD/SD SDI configurable I/O.
  • Adaptive cable equalizer and driver.
  • Data rates up to 2.97Gbps.
  • Equalizes up to 120m of Belden 1694A.
  • Operates from -40°C to 85°C.

LMH0387SLE/NOPB Applications

  • Ideal for broadcast video transmission.
  • Suitable for SDI signal integrity.
  • Used in professional video equipment.
  • Supports DVB-ASI applications.

LMH0387SLE/NOPB FAQs

5 frequently asked questions generated from this part’s specifications.
What is the data rate supported by the LMH0387SLE/NOPB?

The LMH0387SLE/NOPB supports a minimum data rate of 125Mbps when receiving signals.

What is the package type of the LMH0387SLE/NOPB?

The package type is 48-VFQFN.

What standards does the LMH0387SLE/NOPB comply with?

It complies with ST 424, ST 292, ST 344, ST 259, and supports DVB-ASI at 270Mbps.

What is the operating temperature range of the LMH0387SLE/NOPB?

-40°C to 85°C.

What is the supply voltage range for this IC?

The supply voltage ranges from 3.135V to 3.465V.
