| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Automotive Grade | |
| Current | |
| Efficiency | |
| Features | |
| Industrial Grade | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Type | |
| Voltage |
The Bel Power Solutions LME1601-6PG is a ruggedized AC/DC power supply designed for industrial applications. It provides 120W of convection-cooled power with a single 24V adjustable output.
This power supply operates with a universal AC input range of 85 to 264 VAC and includes active power factor correction (PFC). It also supports DC input from 120V to 250 VDC. The device offers high efficiency, at or above 88%, and operates without power derating between -20°C and +50°C.
Designed for versatility, the LME1601-6PG supports various mounting needs, including DIN rail or standard screw metal clips. Its enclosed type and chassis mount make it suitable for ITE (Commercial) applications. The power supply has one regulated output and features like load sharing and universal input.
85-264 VAC and 120-250 VDC.
24V at 5A, 120W.
88%.
-20°C to 50°C.
Enclosed, chassis mount package.
168.5mm x 111.2mm x 38.7mm (L x W x H).
Yes, it includes power factor correction (PFC).
