The LMD400-0048-C940-7030000 is a constant current LED driver from CreeLED, Inc. designed for use with LMH2 series LED light sources. It delivers a 940mA output current over a 22-44V output voltage range, making it suitable for 41W LED loads. The driver accepts a universal AC input of 120-277VAC at 50/60Hz and achieves 87% efficiency.
This driver features analog dimming capability and includes a single output with wire leads for termination. It is rated IP20 for indoor use and NEMA 410 for surge protection. The operating temperature range is 0°C to 90°C, suitable for a variety of ambient conditions.
The compact mechanical package measures 90.0mm x 90.0mm x 37.5mm (3.54" x 3.54" x 1.48"). The driver is approved by CE, CQC, and cULus, ensuring compliance with international safety standards. It is designed for applications such as recessed downlights, wall sconces, and pendant lights in retail, museum, hospitality, and restaurant environments.
The input voltage range is 120-277 VAC at 50/60 Hz.
The driver measures 90.0mm x 90.0mm x 37.5mm (3.54" x 3.54" x 1.48").
The operating temperature range is 0°C to 90°C.
The part is listed as RoHS3 compliant, but this status is unverified.
The output current is 940 mA constant current.
Yes, it supports analog dimming (0-10V).
The driver is approved by CE, CQC, and cULus.
