| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
90,400 pcs
|
90400 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Operating Temperature Range | |
| Output Current | |
| Storage Temperature | |
| Tape & Reel |
The LM5109B from Texas Instruments is a cost-effective, high-voltage gate driver suitable for synchronous buck or half-bridge configurations. It is designed to drive both the high-side and low-side N-channel MOSFETs.
Key electrical specifications include a 1A peak output current (sink and source), fast propagation times of 30 ns typical, and excellent propagation delay matching of 2 ns typical. The device drives a 1000 pF load with 15 ns rise and fall times. It features independent TTL-compatible inputs and supply rail under-voltage lockout for both low-side and high-side power rails.
The LM5109B supports a bootstrap supply voltage up to 90V and operates with an input supply voltage between 8V and 14V. The typical undervoltage lockout is 8V. The device is available in SOIC-8 and WSON-8 (4 mm x 4 mm) packages, both supporting surface mount.
Typical applications include current-fed push-pull converters, half and full bridge power converters, solid-state motor drives, and two-switch forward power converters.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.01 | $2.01 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The LM5109B provides a 1A peak output current, capable of both sinking and sourcing.
The bootstrap supply voltage can be up to 90V.
The typical propagation delay time is 30 ns, with excellent matching of 2 ns.
The operating temperature range is from -40°C to 125°C.
The LM5109B is available in SOIC-8 and WSON-8 packages.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) is 1 Unlimited.
