| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Approval Agency | |
| Automotive Grade | |
| Current | |
| Efficiency | |
| Features | |
| Halogen Free | |
| Height | |
| Industrial Grade | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
This LM450-12B15-C AC/DC converter from Mornsun America, LLC is designed for commercial ITE applications. It provides a stable 15V output with a maximum current of 30A, delivering a total power of 450W.
The converter operates with an input voltage range of 176 to 264 VAC or 240 to 373 VDC, offering flexibility in power sources. It boasts an efficiency of 86% and features like standby output and universal input.
With a chassis mount type, this enclosed unit is suitable for integration into various systems. Its dimensions are 8.47" L x 4.53" W x 1.18" H (215.0mm x 115.0mm x 30.0mm). The operating temperature range is -30°C to 70°C with derating.
Key specifications include a 3 kV isolation voltage and compliance with standard 62368-1. The unit is CE approved.
The LM450-12B15-C provides a 15V output at 30A.
The power rating of the LM450-12B15-C is 450W.
The input voltage range is 176 to 264 VAC or 240 to 373 VDC.
The operating temperature range is -30°C to 70°C with derating.
The LM450-12B15-C uses chassis mount.
Key features include standby output and universal input.
The efficiency is 86%.
