The LM2696EVAL from Texas Instruments is a fully populated evaluation board featuring the LM2696 constant on-time buck regulator. This board is designed to deliver up to 3A into a load, accepting input voltages ranging from 4.5V to 24V. The switching frequency can be set between 100 kHz and 500 kHz, with the evaluation board operating at a typical frequency of 250 kHz.
Key features of the LM2696EVAL include an internal 130 mΩ MOSFET switch, a power-good flag, and TTL compatible shutdown thresholds. The board is supplied as a single board and is housed in an HTSSOP-16 package. Its compact size, measuring 32 mm² (5 mm × 6.4 mm), makes it suitable for space-constrained applications. The evaluation board facilitates the examination of performance tradeoffs through component substitution, allowing for optimization based on specific design constraints.
This evaluation board is ideal for prototyping and testing applications that require efficient DC/DC step-down conversion. It simplifies the design process by providing a pre-built platform for the LM2696 regulator, enabling faster time-to-market for power management solutions.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 4.5 V to 24 V.
The maximum output current is 3 A.
The typical switching frequency is 250 kHz.
The topology is Buck.
The operating temperature range is -40 °C to 125 °C.
The IC is housed in an HTSSOP-16 package.
