The Morning Star Industrial LM15-23B12-Q is an enclosed AC/DC switching power supply designed for reliable power conversion. It accepts a wide input voltage range of 85-305VAC or 100-430VDC, making it suitable for global applications.
This converter delivers a nominal output voltage of 12V with a current rating of 1.3A, providing a total output power of 15.6W. It boasts high efficiency up to 83% and a low no-load power consumption of less than 0.5W. Key electrical specifications include line regulation of ±0.5% and load regulation of ±1% under rated load conditions.
The LM15-23B12-Q operates within an ambient temperature range of -30°C to +70°C and features robust protection against output short circuit, over-current, and over-voltage. Its high I/O isolation test voltage is up to 4000VAC.
Designed for easy integration, this unit features chassis mount capability and measures 65.0mm x 55.0mm x 25.0mm. It is suitable for various industrial applications and meets standards such as IEC/UL/EN62368.
85-305VAC or 100-430VDC.
12V at 1.3A.
-30°C to +70°C with derating.
Up to 83% typical.
4000VAC.
65.0mm x 55.0mm x 25.0mm.
Chassis mount.
