| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4,883 pcs
|
4883 pcs | On Request | 1 | On Request | On Request | 0839P//A/ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Accuracy | |
| Load Capacitance | |
| Mounting Type | |
| Noise | |
| Operating Temperature Range | |
| PSRR | |
| Package / Case | |
| Quiescent Current | |
| Thermal Resistance |
The LM1117S-ADJ is an adjustable linear voltage regulator manufactured by HTC, designed to provide a stable output voltage from an input voltage ranging from 2.6V to 15V. It can supply a maximum output current of 800mA.
This regulator offers a typical dropout voltage of 1200mV and features adjustable output voltage capabilities, with a minimum output voltage of 1.25V and a maximum of 13.8V. It also provides fixed output options including 1.8V, 2.5V, 3.3V, and 5V.
The device exhibits a typical noise level of 38 µVrms and a PSRR of 47 dB at 100 KHz. It is available in various package types, including TO-263, TO-252, WSON, SOT-223, and TO-220, supporting surface mount and through-hole mounting.
The operating temperature range for the LM1117S-ADJ is from -40°C to 125°C, making it suitable for demanding environmental conditions. It includes built-in current limiting and thermal protection.
The input voltage range is 2.6V to 15V.
The output voltage is adjustable from 1.25V to 13.8V.
The maximum output current is 800mA.
The typical dropout voltage is 1200mV.
For the LM1117I variant, the operating temperature range is -40°C to 125°C.
The LM1117S-ADJ is available in TO-263, TO-252, WSON, SOT-223, and TO-220 packages.
The typical noise level is 38 µVrms.
