LM1117DT-ADJ The Texas Instruments LM1117DT-ADJ is an 800mA adjustable positive linear voltage regulator. It features a maximum input voltage of 15V and a typical dropout voltage of 1200mV.
Mfr Part #:

LM1117DT-ADJ

Available from 3 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments LM1117DT-ADJ is an 800mA adjustable positive linear voltage regulator. It features a maximum input voltage of 15V and a typical dropout voltage of 1200mV.
✓ Total Stock: 2,472 pcs
$ Price Range: $0.28

LM1117DT-ADJ Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Non-Authorised Inventory information
2,224 pcs
2224 pcs On Request 1 On Request On Request 9952 On Request On Request
Non-Authorised Inventory information
221 pcs
221 pcs On Request 1 On Request On Request On Request On Request On Request
Non-Authorised Inventory information
27 pcs
27 pcs On Request 1 On Request On Request On Request On Request On Request

LM1117DT-ADJ Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Accuracy
Current
Load Capacitance
Mounting Type
Noise
Number of Regulators
Operating Temperature
Output Configuration
Output Type
PSRR
Protection Features
Quiescent Current
Supplier Device Package
Thermal Resistance
Voltage
Voltage Dropout (Max)

LM1117DT-ADJ Description

Short technical summary and product information.

The LM1117DT-ADJ from Texas Instruments is an 800mA, low-dropout linear voltage regulator. It is designed for use in applications requiring a stable, adjustable positive output voltage.



Key electrical specifications include a maximum input voltage of 15V and a minimum input voltage of 2.6V. The output voltage is adjustable, with a minimum of 1.25V and a maximum of 13.8V. It can deliver up to 800mA of output current. The device offers protection features such as over current and over temperature protection. Its PSRR is rated at 47dB at 100 KHz, and noise is 38 µVrms.



This regulator is available in a TO-252 surface mount package. The operating temperature range is from 0°C to 125°C. It is suitable for various power management applications where a reliable and adjustable voltage source is needed.

LM1117DT-ADJ Quick Information

Product Type: Linear Voltage Regulator
Canonical Name: LM1117DT-ADJ Adjustable Linear Voltage Regulator
Subcategory: Linear

LM1117DT-ADJ Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

LM1117DT-ADJ Estimated Pricing

Qty Low High
1+ $0.28 $0.28

Estimated market price range - modelled values for guidance only, not live distributor offers.

LM1117DT-ADJ Features

  • 800mA adjustable positive linear voltage regulator.
  • Input voltage up to 15V.
  • Adjustable output from 1.25V to 13.8V.
  • TO-252 surface mount package.
  • Over current and over temperature protection.

LM1117DT-ADJ Applications

  • Power management circuits.
  • Adjustable voltage regulation.
  • Low-power electronic devices.
  • Battery-powered systems.

LM1117DT-ADJ FAQs

7 frequently asked questions generated from this part’s specifications.
What is the output current capability of the LM1117DT-ADJ?

The LM1117DT-ADJ can deliver up to 800 mA of output current.

What is the input voltage range for the LM1117DT-ADJ?

The input voltage range is 2.6 V minimum to 15 V maximum.

What is the output voltage range of the LM1117DT-ADJ?

The adjustable output voltage range is from 1.25 V to 13.8 V.

What package is the LM1117DT-ADJ available in?

The LM1117DT-ADJ is available in a TO-252-3, DPak (2 Leads + Tab), SC-63 surface-mount package.

What is the operating temperature range for the LM1117DT-ADJ?

The junction temperature range is 0°C to 125°C.

What protection features does the LM1117DT-ADJ include?

The LM1117DT-ADJ includes over-current and over-temperature protection.

What is the typical dropout voltage of the LM1117DT-ADJ?

The typical dropout voltage is 1200 mV.
