| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Approval Agency | |
| Automotive Grade | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Bel Power Solutions LKP5740-9ERG is an enclosed AC/DC converter with conformal coating, designed for chassis mounting. It delivers 280W of power with dual outputs, each providing 25.68V. The converter boasts a high efficiency of 87% and includes features such as Power Factor Correction (PFC), remote on/off capability, and load sharing.
With an operating temperature range of -40°C to 71°C, this unit is suitable for demanding environments. Its dimensions are 168.0mm in length, 111.0mm in width, and 80.0mm in height. The LKP5740-9ERG is approved by cCSAus, CE, and NEMKO, indicating compliance with safety standards.
This AC DC converter is suitable for ITE (Commercial) and Railway applications, offering reliability and performance for advanced electronic systems. It also features input over- and undervoltage lockout and inrush current limitation for protection.
The LKP5740-9ERG provides 280W of power.
The LKP5740-9ERG has an output voltage of 25.68V.
The LKP5740-9ERG features 2 outputs.
The efficiency of the LKP5740-9ERG is 87%.
The LKP5740-9ERG operates between -40°C and 71°C.
The dimensions of the LKP5740-9ERG are 168.0mm x 111.0mm x 80.0mm.
The power factor is greater than 0.93.
