Mfr Part #:

LFSCM3GA40EP1-5FFAN1020I

Mfr Name: Lattice Semiconductor Corporation

The Lattice Semiconductor LFSCM3GA40EP1-5FFAN1020I is an FPGA with 40,000 logic elements and 562 I/O pins. It features 4.08 Mb of RAM and operates within a voltage range of 0.95V to 1.26V.

✓ Total Stock: 132 pcs

LFSCM3GA40EP1-5FFAN1020I Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Flip Electronics ✓ Non-Authorised Inventory information	132 pcs On Request	132 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

LFSCM3GA40EP1-5FFAN1020I Description

Short technical summary and product information.

The Lattice Semiconductor LFSCM3GA40EP1-5FFAN1020I is a high-performance Field Programmable Gate Array (FPGA) from the LatticeSC/M family. It offers a substantial fabric with 40,000 logic elements and 10,000 LABs, complemented by 4.08 Mb of embedded block RAM and additional distributed RAM. This device supports up to 562 I/O pins, enabling extensive system expansion and connectivity.

Designed for demanding applications, the LFSCM3GA40EP1-5FFAN1020I operates within a flexible voltage range of 0.95V to 1.26V. It features high-speed SERDES capabilities ranging from 600Mbps to 3.8Gbps and PURESPEED I/O supporting up to 2Gbps DDR. The operating temperature range is specified from -40°C to 105°C (TJ), making it suitable for industrial environments.

This FPGA is housed in a 1020-BBGA, FCBGA package, with the supplier's package specified as 1020-OFcBGA Rev 2 (33x33). It is designed for surface mount applications. The device includes advanced clocking features with 8 analog PLLs and 12 DLLs, supporting clock frequencies up to 700MHz globally and 1GHz on edge clocks.

LFSCM3GA40EP1-5FFAN1020I Quick Information

Product Type: FPGA

Series: LatticeSC/M

Canonical Name: LatticeSC/M Family FPGA

Subcategory: Field Programmable Gate Array

LFSCM3GA40EP1-5FFAN1020I Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

LFSCM3GA40EP1-5FFAN1020I Features

40,000 logic elements and 10,000 LABs
562 I/O pins for system connectivity
4.08 Mb embedded block RAM
High-speed SERDES up to 3.8 Gbps
Wide operating temperature range

LFSCM3GA40EP1-5FFAN1020I Applications

High-performance digital signal processing
Complex logic implementation
High-speed data communication
Embedded system design

LFSCM3GA40EP1-5FFAN1020I FAQs

6 frequently asked questions generated from this part’s specifications.

What is the number of logic elements in the LFSCM3GA40EP1-5FFAN1020I FPGA?

The LFSCM3GA40EP1-5FFAN1020I FPGA has 40,000 logic elements.

How many I/O pins does the LFSCM3GA40EP1-5FFAN1020I FPGA offer?

The LFSCM3GA40EP1-5FFAN1020I FPGA offers 562 I/O pins.

What is the operating voltage range for the LFSCM3GA40EP1-5FFAN1020I FPGA?

The operating voltage range for the LFSCM3GA40EP1-5FFAN1020I FPGA is 0.95V to 1.26V.

What is the package type for the LFSCM3GA40EP1-5FFAN1020I FPGA?

The LFSCM3GA40EP1-5FFAN1020I FPGA is supplied in a 1020-OFcBGA Rev 2 (33x33) package.

What is the operating temperature range of the LFSCM3GA40EP1-5FFAN1020I FPGA?

The LFSCM3GA40EP1-5FFAN1020I FPGA operates within a temperature range of -40°C to 105°C (TJ).

What is the total RAM bit capacity of the LFSCM3GA40EP1-5FFAN1020I FPGA?

The LFSCM3GA40EP1-5FFAN1020I FPGA has a total RAM bit capacity of 4,075,520 bits.

Category	FPGAs (Field Programmable Gate Array)
Manufacturer Name	Lattice Semiconductor Corporation
Lead Spacing	33 mm
Mounting Type	Surface Mount
Number of I	562
Number of LABs	10,000
Number of Logic Elements	40,000
Operating Temperature	-40°C ~ 105°C
Supplier Device Package	1020-OFcBGA Rev 2 (33x33)
Supplier Package	1020-OFcBGA Rev 2 (33x33)
Total RAM Bits	4.08 Mb
Voltage	0.95V ~ 1.26V
