LFE3-150EA-7FN672I The Lattice Semiconductor LFE3-150EA-7FN672I is an FPGA with 149000 logic elements and 380 I/O pins. It operates within a voltage range of 1.14V to 1.26V.
Mfr Part #:

LFE3-150EA-7FN672I

Available from 1 distributors
Mfr Name: Lattice Semiconductor Corporation
Lattice Semiconductor Corporation
The Lattice Semiconductor LFE3-150EA-7FN672I is an FPGA with 149000 logic elements and 380 I/O pins. It operates within a voltage range of 1.14V to 1.26V.
✓ Total Stock: 14,146 pcs

LFE3-150EA-7FN672I Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Non-Authorised Inventory information
14,146 pcs
14146 pcs On Request 1 On Request On Request On Request On Request On Request

LFE3-150EA-7FN672I Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Lead Spacing
Mounting Type
Number of I
Number of LABs
Number of Logic Elements
Operating Temperature
Supplier Device Package
Supplier Package
Tape & Reel
Total RAM Bits
Voltage

LFE3-150EA-7FN672I Description

Short technical summary and product information.

The Lattice Semiconductor LFE3-150EA-7FN672I is a Field Programmable Gate Array (FPGA) designed for high logic density and system integration. It features 149,000 logic elements and 18,625 LABs, providing substantial capacity for complex designs. The device offers 380 I/O pins and includes 7,014,400 bits of embedded RAM.



This FPGA supports a wide range of interfaces with its programmable sysI/O buffer, including LVTTL, LVCMOS, SSTL, HSTL, LVDS, and more. It also features embedded SERDES capabilities, supporting data rates from 150 Mbps to 3.2 Gbps per channel, suitable for protocols like PCI Express, Gigabit Ethernet, and Serial RapidIO.



The LFE3-150EA-7FN672I operates within a voltage range of 1.14V to 1.26V and has an operating temperature range of -40°C to 100°C (TJ). It is supplied in a 672-BBGA package with a surface mount type, and the supplier package is specified as 672-FPBGA (27x27).



Key features include flexible memory resources, sysCLOCK Analog PLLs and DLLs, and pre-engineered source synchronous I/O. The device is suitable for various applications requiring high-performance logic and I/O flexibility.

LFE3-150EA-7FN672I Quick Information

Product Type: FPGA
Series: ECP3
Canonical Name: Lattice Semiconductor Corporation LFE3-150EA-7FN672I FPGA
Subcategory: Field Programmable Gate Array

LFE3-150EA-7FN672I Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

LFE3-150EA-7FN672I Features

  • High logic density with 149K LUTs
  • 380 I/O pins available
  • 7.01 Mbit embedded RAM
  • SERDES up to 3.2 Gbps
  • Wide range of I/O standards supported

LFE3-150EA-7FN672I Applications

  • Suitable for high-performance designs
  • Supports serial communication protocols
  • Ideal for system integration needs
  • Flexible I/O for diverse interfaces

LFE3-150EA-7FN672I FAQs

7 frequently asked questions generated from this part’s specifications.
How many logic elements does the LFE3-150EA-7FN672I FPGA have?

The LFE3-150EA-7FN672I FPGA has 149,000 logic elements.

What is the I/O pin count for the LFE3-150EA-7FN672I?

The LFE3-150EA-7FN672I features 380 I/O pins.

What is the total RAM bit count on the LFE3-150EA-7FN672I?

The LFE3-150EA-7FN672I has a total of 7,014,400 RAM bits.

What is the operating voltage range for the LFE3-150EA-7FN672I?

The operating voltage range for the LFE3-150EA-7FN672I is 1.14V to 1.26V.

What is the operating temperature range of the LFE3-150EA-7FN672I?

The operating temperature range is -40°C to 100°C (TJ).

What package is the LFE3-150EA-7FN672I supplied in?

The LFE3-150EA-7FN672I is supplied in a 672-BBGA package, with the supplier package specified as 672-FPBGA (27x27).

What SERDES data rates does the LFE3-150EA-7FN672I support?

The LFE3-150EA-7FN672I supports SERDES data rates from 150 Mbps to 3.2 Gbps.
