The Cosel LFA240F-36-RT is an open frame AC/DC power supply designed for ITE (Commercial) applications. It features a universal input voltage range of 85 to 264 VAC, making it suitable for global use. This converter delivers a stable 36V DC output with a maximum current of 6.7A, providing a total output power of 241.2W.
With a high efficiency rating of 87.5%, the LFA240F-36-RT minimizes energy waste. It incorporates built-in protection circuits for inrush current, overcurrent, and overvoltage, enhancing reliability. The unit is compliant with safety standards such as UL60950-1, CSA60950-1, and EN62368-1, and meets EMI standards like FCC-B and CISPR22-B.
The compact dimensions of 132.1mm x 50.0mm x 26.4mm and chassis mount type allow for easy integration into various systems. It operates within an ambient temperature range of -10°C to 70°C and offers an isolation voltage of 3 kV.
The output voltage is 36V DC.
The maximum output current is 6.7A.
The maximum output power is 241.2W.
The input voltage range is 85 VAC to 264 VAC.
The operating temperature range is -10°C to 70°C.
The dimensions are 132.1mm x 50.0mm x 26.4mm.
