The Cosel LEA75F-12-S is an open frame AC/DC power supply designed for ITE (Commercial) applications. It delivers a stable 12V DC output with a maximum current of 6.3A, providing a total output power of 75W.
Key electrical specifications include a universal input voltage range of 85-264 VAC or 120-370 VDC, and an efficiency of up to 80%. The unit features Power Factor Correction (PFC) for improved power efficiency.
Mechanically, this converter has an open frame construction with dimensions of 222.0mm x 55.0mm x 29.0mm, suitable for chassis mounting. It operates within a temperature range of -20°C to 70°C with derating.
Compliance includes RoHS3, MSL 1, and REACH Unaffected, with an isolation voltage of 3 kV.
85-264 VAC or 120-370 VDC.
-20°C to 70°C with derating.
Chassis mount open frame measuring 222.0mm x 55.0mm x 29.0mm.
12 VDC at 6.3 A.
80%.
3 kV.
Start-up time 500ms maximum, hold-up time 20ms typical.
