The Cosel LEA100F-24 is an open-frame AC/DC power supply designed for ITE (Commercial) applications. It provides a stable 24V DC output with a maximum current of 4.3A, delivering a total power of 100W.
This converter features a universal input voltage range of 85-264 VAC or 120-370 VDC, operating at frequencies between 47-63 Hz. It boasts high efficiency, reaching up to 85% at 200V AC input. Key electrical specifications include a line regulation of 96mV maximum and a load regulation of 150mV maximum. The ripple and noise are kept to 150mVp-p at 0 to +50C.
Designed for chassis mounting, the LEA100F-24 has dimensions of 222.0mm x 62.0mm x 32.0mm. It operates within an ambient temperature range of -10°C to 70°C with derating. Safety features include overcurrent and overvoltage protection, along with high isolation voltages between input, output, and chassis ground.
The output voltage is 24V.
The maximum output current is 4.3A.
The total power output is 100W.
The input voltage range is 85-264 VAC or 120-370 VDC.
The operating temperature range is -10°C to 70°C.
It uses chassis mount.
The approval agencies are CE, cURus, and TUV.
