The Cosel LDA75F-5-L is an open-frame AC/DC converter designed for reliable power delivery in commercial ITE applications. This unit provides a stable 5V output with a maximum current of 15A, delivering a total output power of 75W.
Key electrical specifications include a wide input voltage range of 85 to 264 VAC and 110 to 370 VDC, with an efficiency rating of 79%. The converter offers an isolation voltage of 3kV, ensuring safety and performance.
Mechanically, the LDA75F-5-L measures 222.0mm in length, 55.0mm in width, and 32.0mm in height. It is designed for chassis mounting, making it suitable for integration into various system designs. The operating temperature range is -10°C to 60°C, with derating applied at higher temperatures.
This converter is compliant with safety standards such as cCSAus, CE, cURus, and TUV, and adheres to standard number 60950-1. It also features adjustable output and universal input capabilities.
The Cosel LDA75F-5-L provides a single output of 5V at 15A.
The input voltage range is 85 to 264 VAC or 110 to 370 VDC.
The operating temperature range is -10°C to 60°C with derating.
The efficiency is 79%.
The isolation voltage is 3kV.
It is a chassis mount module with dimensions 222.0mm x 55.0mm x 32.0mm.
It is approved by cCSAus, CE, cURus, and TUV.
